Biostar M7VIG-400 Rev 7.1 Socket A Micro ATX Motherboard, 333FSB, DDR333, Video & 6ch Audio, LAN.
The Biostar M7VIG-400 Socket A Micro ATX Motherboard is a low cost solution with maximum features. The board motherboard features: 333FSB CPU Support, DDR 333 Memory support, AGP 4X, 3 PCI Slots, 1 CNR, Onboard Video, Onboard 10/100 LAN, and 6ch Audio.
# CPU Support: As of Rev. 7.1 of this motherboard the following CPUs are supported: AMD Athlon XP: Up to 3000+ on 333MHz FSB / 2600+ on 266MHZ FSB
# AMD Sempron: Up to 2800+ on 333MHz FSB
# AMD Duron: Up to 1.8GHz on 266MHz FSB / 1.3GHZ on 200FSB
Future revisions of the board may support higher CPUs. We ship at least Rev 7.1
Features & Specifications: Processor AMD Athlon, Athlon XP and Duron Processor, 200 / 266 / 333MHz front side bus. Chipset VIA KM266 Pro / VT8235. Memory 2 x 184-pin DDR DIMM, Maximum 2.0 GB, DDR 333. Slots 1 x AGP, 3 x PCI, 1 x CNR. IDE 4 x EIDE Devices, Ultra DMA33/66/100/133. I/O 1 x Parallel, 1 x serial, 1 x PS/2 mouse, 1x PS/2 keyboard, 1 x Speak-out, 1 x Line-in, 1 x Mic.-in, 1 x Floppy, 4 x Front USB 2.0, 2 Rear USB 2.0, 1 x Front audio header, 1 x LAN RJ45 jack. Video UniChrome 2D/3D Graphics with motion compensation. Audio C-Media CMI9761A 6-Channel AC'97 CODEC. LAN VIA VT6103. Hardware Monitor CPU / System Fan Speed, System Voltage, CPU / System Temperature. Size Micro ATX Form Factor, 24.4cm x 19.4cm (W x L). Certifications CMTL, FCC, CE.
